Advantages: Good corrosion resistance: Marine Resin has good corrosion resistance and can resist the erosion of corrosive media such as sea water and salt spray, extending the service life of the ship.
Application scenarios: Hull manufacturing: Marine Resin is used to make structural components of the hull, such as bottom, hull, deck, etc., which can improve the strength, stiffness and corrosion resistance of the hull.
RC-189C Unsaturated polyester resin
Technical index of liquid resin (25℃):
| Item | Unit | Index | Testing method |
| Appearance | -- | Yellow transparent liquid | GB/T8237.6.1.1 |
| Viscosity | Pa·s | 0.26~0.42 | GB/T7193.4.1 |
| Gel time | min | 11.5~20.5 | GB/T7193.4.6 |
| Acid value | mgKOH/g | 14.0~21.0 | GB/T2895 |
| Non-volatile material | % | 57.0~63.0 | GB/T7193.4.3 |
Physical properties of casting body and FRP (for reference only)
| Item | Unit | Factual Value | Testing Method |
| Tensile Strength | MPa | 70 | GB/T2567-2008 |
| Elastic
Tensile
Modulus | MPa | 3400 | GB/T2567-2008 |
| Elongation at Break | --- | 2.2% | GB/T2567-2008 |
| Bending Strength | MPa | 120 | GB/T2567-2008 |
| Modulus
of
elasticity
(MOE) | MPa | 3600 | GB/T2567-2008 |
| Compressive
Strength
| KJ/m2 | 10.0 | GB/T2567-2008 |
| Heat
Deflection
Temperature | ºC | 78 | GB/T1634-2004 |
| Bacol Hardness | --- | 48 | GB/T3854-2005 |
Instructions:
RC189C resin 100 units
Curing agent (MEKPO) 1 ~ 2 (dosage depends on air temperature)
Accelerator RCA 1-4 (dosage depends on air temperature)
Notices:
The product should be stored in a cool place below 25ºC, avoid fire, and keep away from heat and radiation sources. The shelf life of storage below 25ºC is 3 months after leaving the factory.
FAQ
Our Advantages
Why we choose Changzhou Rule Composite Material Co., Ltd?
What is resin?
Resin usually refers to products inclined to softening or melting after receiving heat. When softening, it shows a trend toward flowing under the influence of external forces. Under normal temperature, it is in solid, semi-solid state, and sometimes liquid organic polymer. Broadly speaking, any macromolecule compound that can be used as a raw material for plastic processing can be called resin.
What can resins do for you?
Resin products are widely used in sectors like railways, automobiles, wind power, shipbuilding, cooling towers, pipelines, coatings, electrical appliances, artificial stone, handicrafts, lighting tiles, sanitary ware, anti-corrosion engineering and so on. Rule has been granted certification of ISO9001: 2008 Quality Management System and ISO14001: 2004 Environmental Management System, and some products have won recognition of China Classification Society(CCS) and Food-Level Licenses of the Provincial Department of Health.
We are the professional resin solution provider.
With decades of experience in the R& D of resins, we can fully understand customers' needs and aspirations in the cooperation process and have presented countless solutions. Over the years, we work hard to optimize our products and make them attractive to end users.
